PC ECG Biocare ECG-2000

The PC ECG Biocare ECG-2000 is delivered with the appropriate software, enabling a paperless workflow as ECGs can be measured and edited directly on the screen. The ECG is delivered as a complete operational set including cables and electrodes. You can also opt for a Biocare ECG-2000 set complete with a laptop.

Product Details for the Biocare PC ECG

• PC ECG Biocare ECG-2000
• The pc-based, 12-lead resting ECG machine
• Real-time graphic representation
• ECGs directly measured and edited on the screen
• Easy reporting in all common data formats (BMP, JPG, Word, XML, Dicom)
• Comprehensive storage and printing options
• Data transfer and power supply via USB

Technical Details for Biocare ECG-2000

• High-performance chip with anti-drift technology
• High-performance data management software
• Pathological results are shown in color
• Sampling rate: 1,000 Hz
• A-D converter 24-bit
• The frequency response of 0.05 – 250 Hz, purpose-built for pediatric diagnostics
• Sensitivity: 5 mm/mV, 10 mm/mV, 20 mm/mV
• Analysis functions: VCG, VLP, HRV, HFECG, FCG, HRT and QT

System Requirements and Configuration

• Operating system: Windows 7 or later, Direct X9.0c, Drivers OFFICE 2000 Word or later
• Computer (recommended configuration): P4 2.0 GHz or higher; HDD: 80 GB or more
• B or more
• High-resolution color display: 1024 x 768 or better
• Printer: print resolution ≥ 600 dpi, laser printer or high-quality inkjet printers are recommended (do not use dot-matrix printers)
